WARNING
l
Set the jack only at the positions shown
here. If the jack is set at a wrong position,
it could dent your vehicle or the jack
might fall over and cause personal injury.
l
Do not use the jack on a tilted or soft sur-
face. Otherwise, the jack might slip and
cause personal injury. Always use the
jack on a flat, hard surface. Before setting
the jack, make sure there are no sand or
pebbles under the jack base.
3. Rotate the jack by hand until the flange
portion (B) fits in the groove (C) at the
top of the jack.
4. Check that the flange portion at the jack-
ing point fits in the groove at the top of
the jack.
Insert the jack bar (D) into the wheel nut
wrench (E). Then put the end of the jack
bar into the shaft’s jack end, as shown in
the illustration.
Slowly rotate the wheel nut wrench until
the tyre is raised slightly off the ground
surface.
WARNING
l
Stop jacking up the vehicle as soon as the
tyre is raised off the ground. It is danger-
ous to raise the vehicle any higher.
l
Do not get under your vehicle while using
the jack.
l
Do not bump the raised vehicle or leave it
sitting on the jack for a long time. Both
are very dangerous.
l
Do not use a jack except the one that
came with your vehicle.
l
The jack should not be used for any pur-
pose other than to change a tyre.
l
No one should be in your vehicle when us-
ing the jack.
WARNING
l
Do not start or run the engine while your
vehicle is on the jack.
l
Do not turn the raised wheel. The tyres
still on the ground could turn and make
your vehicle fall off the jack.
5. Remove the wheel nuts with the wheel
nut wrench, then take the wheel off.
CAUTION
l
Handle the wheel carefully when changing
the tyre, to avoid scratching the wheel sur-
face.
6. Clean out any mud, etc. on the hub sur-
face (F), hub bolts (G) or in the installa-
tion holes (H) in the wheel, and then
mount the spare tyre.
How to change a tyre
8-16
OGKE18E1
For emergencies
8
