Tyre inflation pressures
E01001404313
Item Tyre size Front Rear
Normal tyre
215/70R16 100H
2.4 bar (35 psi) [240 kPa], 2.6 bar (38 psi) [260 kPa]
*1
225/55R18 98H
2.4 bar (35 psi) [240 kPa], 2.6 bar (38 psi) [260 kPa]
*1
Temporary spare tyre
T155/90D16 110M 4.2 bar (60 psi) [420 kPa]
T155/80D17 100M 4.2 bar (60 psi) [420 kPa]
*1
: Above 160 km/h (99 mph)
Check the tyre inflation pressure of all the tyres while they are cold; if insufficient or excessive, adjust to the specified value.
After the tyre inflation pressure has been adjusted, check the tyres for damage and air leaks. Be sure to put caps on the valves.
Wheel condition
E01001802137
1- Location of the tread wear indicator
2- Tread wear indicator
Check the tyres for cuts, cracks and other
damage. Replace the tyres if there are deep
cuts or cracks. Also check each tyre for
pieces of metal or pebbles.
The use of worn tyres can be very dangerous
because of the greater chance of skidding or
hydroplaning. The tread depth of the tyres
must exceed 1.6 mm in order for the tyres to
meet the minimum requirement for use.
Tread wear indicators will appear on the sur-
face of the tyre as the tyre wears, thereby in-
dicating that the tyre no longer meets the
minimum requirement for use. When these
wear indicators appear, the tyres must be re-
placed with new ones. On 4-wheel drive ve-
hicles, when replacement of any of the tyres
is necessary, replace all of them.
CAUTION
l
Always use tyres of the same size, same
type, and same brand, and which have no
wear differences. Using tyres of different
size, type, brands or degree of wear, will in-
crease the differential oil temperature, result-
ing in possible damage to the driving sys-
tem. Further, the drive train will be subjec-
ted to excessive loading, possibly leading to
oil leakage, component seizure, or other seri-
ous faults.
Tyres
10-11
OGKE18E1
Maintenance
10
