Mitsubishi FX0-14 - Page 60

WWW.NNC.IR
0V
S/S
X
24V
Rp
Rb
Figure: 5.8 ENG
☞
Parallel LED (source input)
FRE
☞
DEL en parallèle (Entrée Source)
GER
☞
LED parallel (Source -Eingang)
ITL
☞
LED in parallelo (ingresso source)
ESP
☞
LED en paralelo (entrada Source)
FX
0
FX
0N
5
FX
0
/FX
0N
Series Programmable Controllers
Inputs
5-7
