5.5
Typical wiring
Verdrahtungsbeispiele
Ejemplos de cableado
Exemples de câblage
Esempi di cablaggio
ENG FRE
GER
ITL
ESP
Table:
5.4
Item check
Description de
positions
Positions-
beschreibung
Descrizione delle
posizioni
Descripción de
posición
REF.
1
AC service supply Tension de service CA AC Servicespannung Tensione di servizio AC Tensión de servicio CA
2
Switch Interrupteur Schalter Interruttore Interruptor
3
Push button Bouton-poussoir Drucktaster Pulsante Pulsador
4
Contact Contact Kontakt Contatto Contacto
5
PC MPU (base unit) Appareil de base API SPS-Grundgerät Apparecchio base PC Unidad base PC
ENG
FRE GER
ITL
ESP
X0 X1 X2com
1
3 4
5
FX0N-**MR-UA1/UL
2
L N
Figure: 5.9 FX
0N
-
✰✰
MR-UA1/UL
5
FX
0
/FX
0N
Series Programmable Controllers
