Mitsubishi FX3U-16CCL-M User Manual

10 Buffer Memory
10.12 Link special relay/Link special register (SB/SW)
126
FX3U-16CCL-M User's Manual
SW009C 69CH 1692
Loading/parameter
consistency status
Stores the consistency with parameters.
(The status is checked and stored only at link startup and at
parameter update.)
A consistency error occurs in any of the following cases.
1) Station type mismatch
*
2) Number of occupied stations mismatch
3) Expanded cyclic setting mismatch
*
4) CC-Link compatible version mismatch
*A consistency error will not occur when installation ≤ parameter.
(For example, a consistency error will not occur when a remote
device station is installed and the parameter setting is an
intelligent device station.)
0: Normal
1: Consistency error
Example of consistency error
Numbers 1 to 16 above indicate station numbers.
(Only the bit corresponding to the head station number is set to
ON.)
Reserved stations and any station of the number higher than the
max. are excepted.
R/O
SW00B4 6B4H 1716 Line test 1 result
Stores the line test 1 result.
0: Normal
1: Error
Numbers 1 to 16 above indicate station numbers.
(Bits corresponding to as many as the number of occupied stations
are set to ON.)
R/O
SW00B8 6B8H 1720 Line test result
Stores the line test 1/line test 2 result.
0: Normal
Other than 0: Stores the error code (Refer to Section 16.3.).
R/O
SW0140 740H 1856
Compatible CC-Link
ver. information
Indicates the remote stations/intelligent device station compatible
with CC-Link ver. 2.
0: Ver. 1 compatible remote station/intelligent device station
1: Ver. 2 compatible remote station/intelligent device station
Numbers 1 to 16 above indicate station numbers.
(Bits corresponding to as many as the number of occupied stations
are set to ON.)
Reserved stations and any station of the number higher than the
max. are excepted.
R/O
SW No.
BFM No.
Name Description
Applicability
( : Applicable,
: Not applicable)
R/W
Hex. Dec. Online Offline
Loading Parameter
Remote device station Remote I/O station
Intelligent device station
Remote I/O station
Remote device station
16 15 14 13 to 4 3
b15b14b13b12 to b3 b2
2 1
b1 b0
SW009C
16 15 14 13 to 4 3
b15b14b13b12 to b3 b2
2 1
b1 b0
SW00B4
16 15 14 13 to 4 3
b15b14b13b12 to b3 b2
2 1
b1 b0
SW0140
