Service Manual Mitsubishi L-Series diesel engines
Version 08/2004
ENGLISH
CAMSHAFTS (VALVE AND INJECTION
PUMP) ENGINE MAIN PARTS
14.3 Inspection
Check the removed parts. If any parts are found
defective, repair or replace them.
Cam lobe-wear
and damage
Bend
Cam contact surface-wear
and damage
Cam lobe-wear
and damage
Journal bearing-wear
and damage
Each ball bearing-wear
and noise
Oldham’s coupling-wear
Rod end-wear
and damage
Figure 64 Inspection of camshafts
Standard
value
Service
limit
Major diameter of injection
pump cam
30
[1.1811]
-0.7
[-0.0276]
Major diameter of valve cam 27.37
[1.0776]
-1.0
[-0.0394]
Table 24 Inspection of camshafts, unit in mm [in.]
