IGNITION TIMING AND DISTRIBUTION CONTROL
MULTIPORT FUEL SYSTEM (MFI)
13A-7
IGNITION TIMING AND DISTRIBUTION CONTROL
M2132005000136
The ignition timing and distribution control is basi-
cally the same as that for the 2.4L engine installed in
the ECLIPSE.
.
System Configuration Diagram
AK203777
SPARK
PLUG
CYLINDER NO.
TO TACHOMETER
IGNITION SWITCH
BATTERY
IGNITION
COIL B
IGNITION
COIL A
23 41
ECM
VOLUME AIRFLOW SENSOR
BAROMETRIC PRESSURE SENSOR
INTAKE AIR TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE
SENSOR
CRANKSHAFT POSITION SENSOR
CAMSHAFT POSITION SENSOR
VEHICLE SPEED SENSOR
KNOCK SENSOR
IGNITION SWITCH-ST
DIAGNOSTIC TEST MODE
AB
