3 Controller
Magnet contactor control connector output (AXMC) for addition axes 3-60
Fig.3-19 EMGOUT connector (CR1DA-700 series)
EMGOUT
EMGOUTコネク配列
6A
5A
4A
3A
2A
1A
6B
5B
4B
3B
2B
1B
内部回路構成
5B
6B
5A
6A
EMGOUT1
EMGOUT2
加軸用
コントール
(AXMC1)
付加軸用コンクタ
コントロール出力
(AXMC2
(お客様 コントローラ側)
AWG#24~#18
(0.2~0.75mm
2
)
電線差込み口
マイ
メーカタイコトロニクスアンプ
型名 :1-1871940-6
EMGOUT1
EMGOUT2
<CR1DA-700 series>
EMGOUT
<Reference>
The connection method of the electric wire is
the same as connection of the emergency
stop.
Please refer to Page 50, "3.6.1 Connection of
the external emergency stop" .
EMGOUT connector
Electric wire plug area
Minus driver plug area
Type 1-1871940-6
Internal circuit
Contactor control output
for addition axes
(AXMC2)
Contactor control output
for addition axes
(AXMC1)
(Controller)
(Custmer)
* The figure is standard specification.
(CE marking specification is the same.)
