4 INTELLIGENT COMMUNICATION MODULE REPLACEMENT
4 - 16
: Compatible, : Partial change required, ×: Incompatible
Output
signal
AD51H-S3
QD51
QD51-R24
Compat-
ibility
Precautions for replacement
Y0
Unused
(Can be used for internal relay (M).)
General output
Change "Y10 to Y20" to "Y0 to Y10"
and "Y13 to Y18".
In addition, change "Y21 to Y28" to
"Y11 to Y12" with the task divided
into two.
Y1
Y2
Y3
Y4
Y5
Y6
Y7
Y8
Y9
YA
YB
YC
YD
YE
YF
Y10
General output
Y11
General output/Start BASIC
task No.1 designation
Y12
General output/Start BASIC
task No.2 designation
Y13
General output
Y14
Y15
Y16
Y17
Y18
Y19 Task start signal
Y1A Reset request signal
Y1B
Use prohibited
Y1C
Y1D
Y1E
Y1F
Y20
Outside I/O point range
Y21
General output/Start BASIC task No.
designation
Y22
Y23
Y24
Y25
Y26
Y27
Y28
Y29 Program start signal
Y2A
Use prohibited
to
Y2F
