3 ETHERNET INTERFACE MODULE REPLACEMENT
3 - 27
(2) Q series
The Q series performs initial processing by setting the following items in the GX Developer network
parameters.
• "Network Parameter Setting the Number of Ethernet/CC IE/MELSECNET Cards"
• "Operational settings"
• "Initial settings"
When replacing the A/AnS series with the Q series, delete the A/AnS series' sequence program for
initial processing.
(a) Program conditions
Set as follows in the GX Developer network parameters:
• IP address: A20009C0H (162.0.9.192)
• Other than IP address: Use default values.
(b) Network parameter setting example
1) "Network parameters Setting the number of Ethernet/CC IE/MELSECNET cards"
