6. NORMAL GAIN ADJUSTMENT
6 - 12
(f) If a warning occur
If a warning occurs during tuning, the alarm No. of the warning will be displayed.
When the warning is one which continue the motor driving, the one-touch tuning will be
continued.
One-touch tuning in progress
Alarm display (warning)
(g) Clearing one-touch tuning
Refer to table 6.1 for the parameters which you can clear.
You can initialize the parameters changed by the one-touch tuning with the clear mode. You can
reset the parameters to before tuning with the back mode.
1) Push the "MODE" button to switch to the initial screen ("AUTO") of the one-touch tuning.
2) Select the clear mode or back mode with the "UP" or "DOWN" button.
One-touch tuning clear mode selection
DOWNUP
To clear the one-touch tuning, push the "SET" button for 2 s.
The one-touch tuning clear mode is in progress.
The clear mode symbol flickers for 3 s.
Clearing one-touch tuning is completed, the initial screen will be displayed.
One-touch tuning clear mode display (initializing)
Initial screen
Auto mode
Clear mode
Back mode
To Next Page
