11. OPTIONS AND AUXILIARY EQUIPMENT
11 - 32
(5) Crimp terminals for P+ and N- terminals of servo amplifier
(a) Recommended crimp terminals
POINT
Always use recommended crimp terminals or equivalent since some crimp
terminals cannot be installed depending on the size.
Servo amplifier Brake unit
Number of
connected
units
Crimp terminal (Manufacturer)
(Note 1)
Applicable
tool
MR-J4-500A(-RJ) FR-BU2-15K 1 FVD5.5-S4 (JST) a
200 V
class
2 8-4NS (JST) (Note 2) b
FR-BU2-30K 1 FVD5.5-S4 (JST) a
MR-J4-700A(-RJ) FR-BU2-15K 2 8-4NS (JST) (Note 2) b
FR-BU2-30K 1 FVD5.5-S4 (JST) a
MR-J4-11KA(-RJ) FR-BU2-15K 2 FVD8-6 (JST) c
FR-BU2-30K 1 FVD5.5-6 (JST) a
FR-BU2-55K 1 FVD14-6 (JST) d
MR-J4-15KA(-RJ) FR-BU2-15K 2 FVD8-6 (JST) c
FR-BU2-30K 1 FVD5.5-6 (JST) a
FR-BU2-55K 1 FVD14-6 (JST) d
MR-J4-22KA(-RJ) FR-BU2-55K 1 FVD14-8 (JST) d
MR-J4-500A4(-RJ) FR-BU2-H30K 1 FVD5.5-S4 (JST) a
400 V
class
MR-J4-700A4(-RJ) FR-BU2-H30K 1 FVD5.5-S4 (JST) a
MR-J4-11KA4(-RJ) FR-BU2-H30K 1 FVD5.5-6 (JST) a
FR-BU2-H55K 1 FVD5.5-6 (JST) a
MR-J4-15KA4(-RJ) FR-BU2-H55K 1 FVD5.5-6 (JST) a
MR-J4-22KA4(-RJ) FR-BU2-H55K 1 FVD5.5-8 (JST) a
FR-BU2-H75K 1 FVD14-8 (JST) d
Note 1. Symbols in the applicable tool field indicate applicable tools in (4) (b) of this section.
2. Coat the crimping part with an insulation tube.
(b) Applicable tool
Servo amplifier-side crimp terminals
Applicable tool
Symbol
Crimp terminal
Body Head Dice
Manufacturer
a
FDV5.5-S4
FDV5.5-6
YNT-1210S
b 8-4NS YHT-8S
c
FVD8-6 YF-1
E-4
YNE-38 DH-111
DH-121
d
FVD14-6
FVD14-8
YF-1
E-4
YNE-38 DH-112
DH-122
JST
