Features and controls
3-283
3
Cargo area cover (if so equipped)
N00528300127
To use
1. Pull out the spring-loaded cover and insert it in the mount-
ing grooves (A) on both sides.
2. Remove the cover from the mounting grooves, and the
cover will be rolled back into the retracted position.
OTE
● Do not place anything on the cargo area cover.
WARNING
!
● For vehicles equipped with third row seat, when the
third row seat is in use, always remove the cargo
area cover to avoid serious injury or death at an
accident.
