8 - 7 8 - 7
MELSEC-Q
8 UTILITY PACKAGE (GX Configurator-MB)
(2) Data created with the utility package
The following data or files that are created with the utility package can be also
handled in GX Developer. Figure 8.1 shows respective data or files are handled
in which operation.
<Intelligent function module parameter>
(a) Initial settings and auto refresh settings are saved in an intelligent function
module parameter file in a project created with GX Developer.
Project
Program
Parameter
PLC parameter
Network parameter
Intelligent function module parameter
(b) Steps 1) to 3) shown in Figure 8.1 are performed as follows:
1) From GX Developer, select:
[Project]
[Open project]/[Save]/[Save as]
2) On the intelligent function module selection screen of the utility, select:
[Intelligent function module parameter]
[Open parameters]/[Save
parameters]
3) From GX Developer, select:
[Online]
[Read from PLC]/[Write to PLC] "Intelligent function module
parameter"
Alternatively, from the intelligent function module selection screen of the
utility, select:
[Online]
[Read from PLC]/[Write to PLC]
To Next Page
