8 - 8 8 - 8
MELSEC-Q
8 UTILITY PACKAGE (GX Configurator-MB)
<Text files>
A text file can be created by clicking the Make text file button on the initial
setting, Auto refresh setting, or Monitor/Test screen.
The text files can be utilized to create user documents.
Programmable
controller CPU
RUN.
ERR.
USER.
BAT.
BOOT.
RS-232
USB
Q25HCPU
MODE.
A
A
B
1)
2)
3)
A
GX Developer/
GX Configurator-MB
Project Project
Disk
A:
B:
Intelligent function module
parameters.
Data saved by "Make text file"
Personal computer
Figure 8.1 Correlation chart for data created with the utility package

Mitsubishi QJ71MT91 Specifications

General

Communication Protocol	MELSECNET/H
Number of Ports/Connections	1
Data Rate/Transmission Speed	10 Mbps
Number of Connectable Stations	64
Occupied Slot	1
Weight	0.2 kg
Model	QJ71MT91
Power Supply	5 V DC
Type	MELSECNET/H communication module
Compatible Controllers	MELSEC-Q Series
