9 - 20 9 - 20
MELSEC-Q
9 PROGRAMMING
(3) Auto refresh setting
Make auto refresh setting from the Auto refresh setting screen of GX
Configurator-MB.
Set the following items for the program example.
Setting Item
Module side
Transfer word count
Module side
Buffer offset
PLC side
Device
Automatic communication function buffer input area 64 256(100H) D4096
Automatic communication function buffer output area 100 2560(A00H) D5000
Automatic communication operation status
D4092
(4) Automatic communication function
For a program example for error code acquisition at an automatic communication
error, refer to <<Handling of automatic communication error>> in (5).
POINT
The automatic communication error code can be monitored on the "Automatic
communication status" screen of GX Configurator-MB.
