Service Manual Mitsubishi SQ-Series diesel engines
Version 08/2004
CYLINDER HEADS AND VALVE
MECHANISM
ENGLISH
ENGINE MAIN PARTS
5. Adjust the valve clearance on the remaining
cylinders by turning the crankshaft 180° at a time,
in the firing order.
Sequence (cylinder No.) Turning angle
1–3–4–2
180°
CAUTION
After adjusting the valve clearance on all cylinders,
turn the crankshaft two or three turns and recheck the
clearance.
