Service Manual Mitsubishi SQ-Series diesel engines
V
ersion 08/2004
TIMING GEARS, CAMSHAFT AND OIL
PAN
ENGLISH
ENGINE MAIN PARTS
ENGINE MAIN P
ARTS
9
TIMING GEARS,
CAMSHAFT AND OIL
PA
N
9.1
Disassembly
1.
Crankshaft pulley
2.
Cover
3.
T
iming g
ear case
4.
Baffle plate
5.
Idler gear
6.
Oil pan
7.
Oil pump
8.
Camshaft
9.
Front en
d plate
Figure 58
Disasse
mbly sequence
8
9
3
7
1
6
5
2
4
42
