8
-
!7
@0
!8
!9
Note: Directions of setting parts of !7 to
@0
as shown in the pictorial below.
Number of Screws : The number of Screws holding Parts.
Table 2-7-2
OPTICAL UNIT2 Part
Parts Name
Number of Screws
!7
PBS Unit none
!8
Polarizer (G) none
!9
Polarizer (B) none
@0
Polarizer (R) none
Fig. 2-7
Table. 2-7-1
!7
!8!9@0
Light source side (Lamp side)
Flat surface
Flat surface
Uneven surface
shaved edge
Surface to stick the
polarizer on
Projection lens side
Parts List : See Parts List Page 5.
Directions which the setting parts face in
RGB Marking
