1 975D152O70 TOP CASE ASSY include 2, 3 [SL2U]
1 750A472O10 TOP CASE ASSY include 2, 3 [XL2U]
2 439B001O20 MEMBRANE SWITCH CONTROL SW
3 480P068O10 SPEAKER
4 761B381O80 TERMINAL BOARD [SL2U]
4 761B381O70 TERMINAL BOARD [XL2U]
5
-----
TERMINAL ASSY
(MAIN PCB ASSY, INLET PCB ASSY, TERMINAL PCB ASSY)
!
6
-----
LAMP POWER ASSY include 7, 8
*
!
7 939P875O10 LAMP POWER UNIT [SL2U]
*
!
7 939P931O10 LAMP POWER UNIT [XL2U]
*
!
8 935D615O01 PREAMP PCB ASSY
!
9
-----
POWER ASSY
*
!
10 935D617O01 SENSOR PCB ASSY
11
-----
OPTICAL UNIT
12
-----
EXHAUST DUCT
13
-----
AUDIO ASSY
14 620D053O20 AIR FILTER
15 752C265O20 FILTER COVER include !4
16 750A473O30 BOTTOM CASE UNIT include !2, !4, !5, !7, !8, !9 [SL2U]
16 750A473O10 BOTTOM CASE UNIT include !2, !4, !5, !7, !8, !9 [XL2U]
17 436P021O10 MICRO SWITCH
18 752C271O00 LAMP COVER
19 589B014O10 ADJUSTMENT FOOT FRONT
ITEM
NO.
PARTS NO. PARTS NAME
EXPOSED VIEW
DESCRIPTION
LVP ASSY (Fig. 2-1)
The PARTS on this page correspond to ones on page 4 in the EXPOSED file.
-
3
-
To Next Page
