11. Specications
■ Individual specications
Model *1 ID-S1012X, ID-S1012XB ID-S112X, ID-S112XB ID-S112PX, ID-S112PXB
Code No. *1 543-781, 543-781B 543-790, 534-790B 543-794, 543-794B
Measurement range 12.7 mm
Resolution 0.01 mm 0.001 mm
Error of indication for
the total measuring
range MPE
E
*2
0.02 mm 0.003 mm
Hysteresis
MPE
H
*2 0.02 mm 0.002 mm
Repeatability
MPE
R
*2
0.01 mm 0.002 mm
Stem diameter ø8 mm
Contact point Carbide (joint screw M2.5 x 0.45), part No. 901312 (provided as standard)
Measurement force
MPL
1.5 N or less 2.5 N or less
Measurement direction All directions
Protection level *3 IP42 equivalent *4 IP53 equivalent *4
Battery life *5 Continuous operation
approx. 20,000 hours
Continuous operation approx. 18,000 hours
Model *1 ID-S1012MX, ID-S1012MXB ID-S112MX, ID-S112MXB ID-S112PMX, ID-S112PMXB
Code No. *1 543-782, 543-782B 543-791, 534-791B 543-795, 543-795B
Measurement range 12.7 mm/0.5 in
Resolution 0.01 mm/0.0005 in 0.001 mm/0.00005 in
Error of indication for
the total measuring
range MPE
E
*2
0.02 mm 0.003 mm
Hysteresis
MPE
H
*2 0.02 mm 0.002 mm
Repeatability
MPE
R
*2
0.01 mm 0.002 mm
Stem diameter ø8 mm
Contact point Carbide (joint screw M2.5 x 0.45), part No. 901312 (provided as standard)
Measurement force
MPL
1.5 N or less 2.5 N or less
Measurement direction All directions
Protection level *3 IP42 equivalent *4 IP53 equivalent *4
Battery life *5 Continuous operation
approx. 20,000 hours
Continuous operation approx. 18,000 hours
Model *1 ID-S1012EX,
ID-S1012EXB
ID-S112EX,
ID-S112EXB
ID-S112TX,
ID-S112TXB
ID-S112PEX,
ID-S112PEXB
Code No. *1 543-783, 543-783B 543-793, 534-793B 543-792, 534-792B 543-796, 543-796B
Measurement range 0.5 in/12.7 mm
Resolution
0.0005 in/0.01 mm 0.00005 in/0.001 mm 0.0001 in/0.001 mm 0.00005 in/0.001 mm
Error of indication for
the total measuring
range MPE
E
*2
0.0020 in 0.0002 in
Hysteresis
MPE
H
*2 0.0010 in 0.0001 in
Repeatability
MPE
R
*2
0.0005 in 0.0001 in
Stem diameter 3/8 in diameter (ø9.52 mm)
Contact point Carbide (joint screw No. 4-48UNF), part No. 21BZB005 (provided as standard)
Measurement force
MPL
1.5 N or less 2.5 N or less
Measurement direction All directions
Protection level *3 IP42 equivalent *4 IP53 equivalent *4
Battery life *5
Continuous operation
approx. 20,000 hours
Continuous operation approx. 18,000 hours
*1: Model numbers ending with "B" are at back types without lug.
*2: During normal measurement at 20 °C.
*3: The protection level (IP: International Protection) is based on IEC 60529/JIS C 0920.
*4: Values are for factory default conditions.
*5: The battery life varies depending on usage times and conditions. The above values are guidelines.
■ Common specications
CE Marking EMC Directive: EN 61326-1
Immunity test requirement: Clause 6.2 Table 2
Emission limit: Class B
RoHS Directive: EN IEC 63000
Power Silver oxide battery SR44 x 1 (part No. 938882)
Scale type Static capacitive type absolute linear encoder
Response speed Unlimited (unavailable for scanning measurement)
Data output Digimatic output
Temperature range
Operating temperature range: 0 °C to 40 °C, storage temperature range: -10 °C to 60 °C
Standard accessory SR44 (for function verication x 1) • User's Manual warranty, inspection results
12. Accessories (Optional)
• Lifting lever: Part No. 21EZA198 (mm)
• Lifting lever: Part No. 21EZA199 (in)
• Lifting knob: Part No. 21EZA105 (mm)
• Lifting knob: Part No. 21EZA150 (in)
• Release: Part No. 540774
• Connection cable: Part No. 905338 (1 m, at straight)
• Connection cable: Part No. 905409 (2 m, at straight)
* For accessories (optional) other than the above, refer to the Mitutoyo MEASURING INSTRU
-
MENTS CATALOG.
13. O󰀨-Site Repairs (Subject to Charge)
O󰀨-site repair (subject to charge) is required in the case of the following malfunctions. Contact your
nearest dealer or our sales o󰀩ce.
• Poor spindle operation
• Poor accuracy
• [E] is displayed as the last digit when the spindle is stationary
• Abnormal measured value or LCD trouble
• No recovery from [Err C]
• Power will not turn on
* If the fundamental structural components or multiple components need to be replaced, we reserve
the right to decline the repair.
