[1] Projector head

[2] Projection screen

[3] Screen rotating knob

[4] Screen clamp knob

[5] Angle counter

[6] XY counter

[7] Projection lens

[8] Reflected illuminator, Condenser lens for reflected illuminator

[9] Cross-travel stage

[10] Control panel

[11] Contour illuminator (interior)

[12] Focusing wheel

[13] Power panel

[14] XY counter output connector

1.1.2 Control panel

[3] [2] [1]

[1] Main switch (Power switch) (|:ON / }:OFF)

[2]

Contour illumination brightness selector switch

[3] Reflected illumination switch (

|:ON / }:OFF)

1 - 2 No.99MBA043A
