Specifications
6.1 General
6
6.1.1 Common specifications
1. Protractor screen
Effective measurement diameter: φ315mm (12.4")
Angle display: Digital
Measuring range: ±360°
2. Projection lens
10X (Standard accessory)
20X, 50X, 100X (Optional accessory)
3. Illumination unit
Contour illumination :
Telecentric illumination with 2-stage intensity selector, Halogen bulb(built-in): 24V
150W, Average life 500 hours
Reflected illumination :
Vertical and oblique surface illumination, Halogen bulb(built-in): 24V 150W, Average
life:500 hours
4. Magnification accuracy
Contour illumination : ±0.1 % or less
Reflected illumination : ±0.15% or less
5. Power supply
Specification for the 100 V-system region : 100,110,120VAC (50/60Hz)
Specification for the 200 V-system region : 220,230,240VAC (50/60Hz)
No.99MBA043A 6 - 1
