4. Place the linear encoder connector into the projector.
5.
Connect the signal cables from the circuit board in the projector to the connector.
6. Attach the cable outlet cover.
Connector for
Linear encoder
The cross-travel stage should be secured when the adjustment of its travel direction is complete.
(Refer to “2.5.2 Aligning the cross-travel stage travel direction to the cross-hair lines”.)
TIP
2 - 8 No.99MBA043A
