Mitutoyo Measuring Projector User Manual

2. Installation and Setup
Clamp knob
Frame of the reflected
illumination condenser
lens
• For the vertical position adjustment of reflected illuminator, loosen the clamp knob to adjust with the
clamp knob or the frame of reflected illumination condenser lens.
No.99MBA043A 2 - 15
