Mitutoyo Measuring Projector User Manual

3. Operation
• For cylindrical workpieces : V-block and clamp (No. 172-378)
• For light-weight, flat workpieces which are difficult to fix : Clamp (No.176-107)
• For screws or cylindrical workpieces with center holes : Swivel center support
(No.176-105, No.172-197)
• Detach the stage glass, when the Swivel center support is installed. (refer to “5.3.3”)
Swivel center support
Workpiece
Sta
g
e
g
lass
T-groove
T-groove
Cross-travel sta
g
e
Cross-travel sta
g
e
Work
p
iece
Clam
p
V-block and clam
p
Work
p
iece
Sta
g
e
g
lass
No.99MBA043A 3 - 3
