Mitutoyo Measuring Projector - Page 59

Step Procedure Screen Counter Display
7 Rotate the protractor screen to
measure
θc.
8 Measure θ
3
.
(
θ
3
is displayed when switching
to the ABS mode.
)
3 - 20 No.99MBA043A
