4) Error
Next error code is output, when the error arises in the counter.
RS232C error code Display Error cause Remedy (method of return)
NG05CRLF
E51
Parity error
arising
NG07CRLF
E52
Over-run error
arising
NG08CRLF
E53
framing error arising
1)Press the X-axis zero-set
button.
2)
Transmit C0 (zero) command
from the peripheral equipment
at RS232C.
NG09CRLF
-
Receiving the
un-defined command
Correspond by the normal
command.
XE20CRLF
E20
X-axis overspeed
arising
1)
Press the X-axis zero-set
button.
2)
Transmit C0 (zero) command.
YE20CRLF
E20
Y-axis overspeed
arising
1)
Press the Y-axis zero-set
button.
2)
Transmit C0 (zero) command.
QE20
CR L F
E-oS
Q-axis overspeed
arising
1)Press the Q-axis zero-set
button.
2)Transmit C0 (zero) command.
XF30CRLF
F30
X-axis overcount
arising
YF30CRLF
F30
Y-axis overcount
arising
Return to the range in which the
counting is possible.
QF30
CR L F
E-oF
Q-axis overcount
arising
1)Press the Q-axis zero-set
button.
2)Return to the range in which
the counting is possible.
TIP
The error with high priority is displayed, when the multiple error phenomena arises
simultaneously. If the error is canceled by C0 (zero) command, etc., the error with next high
priority is displayed.
6 - 8 No.99MBA043A
