(2) Output data format
Each measurement is transmitted as 13-digit serial data. Each digit consists of a 4-bit
data that represents 0 to F(hexadecimal). Output is sequential starting with the LSB(least
significant bit). The table on the right shows the assignments of the 13 digits.
Example of output data
d1 d2 d3 d4 d5 d6 d7 d8 d9 d10 d11 d12 d13
F F F F 8 0 1 2 3 4 5 3 0
d5 d6~d11 d12 d13
-012345x10
-3
mm → -12.345mm
Digit Assignment Data
d1
d2
d3
d4
Not used F(1111)
F(1111)
F(1111)
F(1111)
d5 Sign + : 0(0000)
- : 8(0001)
MSD (most significant digit)
d6
d7
d8
d9
d10
d11
Measured data
(6-digit BCD)
LSD (least significant digit)
d12 Magnification x10
-0
: 0(0000)
x10
-1
: 1(0000)
x10
-5
: 5(1010)
d13 Unit mm : 0(0000)
inch : 1(1000)
6 - 12 No.99MBA043A
