MIXER PLUS Series - Dimensions of the Machine

Manual instruction Mixer Plus Mixer Technology srl pag.5
The models available of the machine: MIXING PUMP MIXER PLUS
MODELS
POWER SUPPLY
POWER
WATER SUPPLY
PLUS MONO 2,2 KW
2 x 230 Volt
3,7 kw
Water
PLUS MONO 3 KW
2 x 230 Volt
3,7 kw
Water
PLUS MONO
STANDARD
3 x 400 Volt
7,4 kw
Water
PLUS MONO TOP
3 x 400 Volt
7,4 kw
Water
PLUS MONO CD25
3 x 400 Volt o 2 x
230 Volt
3,7/7,4
kw
Water
Operating temperature: minimum+5°C, maximum +35°C
Protection grade of switchboard: IP44
Water pump flow rate: 40 litres/min
Compressor air flow rate: 240 litres /min
Flow rate: 6-50 litres /min
Hopper capacity: 80 litres
Max. served distance: 40 meters
Weighted noise pressure level “A”: 92 dB
If the withdraw water is from a deposit, tub or well, it’s require insert a cleaner upline
of the machine.
Accessories upon request: Fairing for feeding from silo
DIMENSIONS OF THE MACHINE
MODEL
DIMENSIONS (cm)
WEIGHT
(without tubes)
PLUS MONO 2,2 KW
A=155 B=110 C=66
215 kg
PLUS MONO 3 KW
A=155 B=110 C=66
215 kg
PLUS STANDARD
A=155 B=110 C=72
240 kg
PLUS TOP
A=155 B=110 C=72
240 kg
PLUS CD25
A=155 B=110 C=72
240 kg
A= Height B= Width C= Depth
