MKS T3B Series User Manual

28
Table
8: Setpoint Messages (continued)
Description Command Request Response
Gain
M x value
x:
1 = Gain SP A
2 = Gain SP B
3 = Gain SP C
4 = Gain SP D
5 = Gain SP E
6 = Gain Analog SP
value:
0 to 32767
R xx
xx: 46 = Gain SP A
47 = Gain SP
B
48 = Gain SP C
49 = Gain SP D
50 = Gain SP E
54 = Gain SP Analog
M x value
x:
1 = Gain SP A
2 = Gain SP B
3 = Gain SP C
4 = Gain SP D
5 = Gain SP E
6 = Gain SP Analog
value
: 0 to 32767
Phase
X x value
x: 1 = Phase SP A
2 = Phase SP B
3 = Phase SP C
4 = Phase SP D
5 = Phase SP E
6 = Phase SP Analog
value: 0 to 32767
R xx
xx: 41 = Phase SP A
42 = Phase SP B
43 = Phase SP C
44 = Phase SP D
45 = Phase SP E
53 = Phase SP Analog
X x
value
x:
1 = Phase SP A
2 = Phase SP B
3 = Phase SP C
4 = Phase SP D
5 = Phase SP E
6 = Phase SP Analog
value: 0 to 32767
Gain
Compensation
Factor
GCvalue
value:
0 to 100.0%
RGC
GC
value
value: 0 to 100.0%
Phase
Compensation
Factor
PCvalue
value:
0 to 100.0%
RPC
PC
value
value: 0 to 100.0%
Softstart Rates
I x value
x:
1 = Setpoint A
2 = Setpoint
B
3 = Setpoint C
4 = Setpoint D
5 = Setpoint E
6 = Analog Setpoint
7 = Valve open
8 = Valve close
value:
0.1 to 100%
full speed
R xx
xx: 15 = Setpoint A
16 = Setpoin
t B
17 = Setpoint C
18 = Setpoint D
19 = Setpoint E
20 = Analog Setpoint
21 = Valve open
22 = Valve close
I x value
x:
1 = Setpoint A
2 = Setpoint B
3 = Setpoint C
4 = Setpoint D
5 = Setpoint E
6 = Analog Setpoint
7 = Valve open
8 = Valve close
value: 0.1 to 100%
full speed
Process Limit
Relays
P x value
x:
1 = Low - PL1
2 = High - PL
1
3 = Low - PL2
4 = High - PL
2
value:
pressure limit
R xx
xx: 11 = Low - PL1
12 = High - P
L1
13 = Low - PL2
14 = High - PL2
P x value
x:
1 = Low - PL1
2 = High - PL1
3 = Low - PL2
4 = High - PL2
value: pressure
li
mit
