MKS T3B Series User Manual

12
Setup Messages
The Setup messages configure the operating parameters for the unit.
Table 6: RS-232 Setup Messages
Description Command Request Response
Stop Calibrating
Valve
Q
N/A N/A
Reset (power cycle)
IX
Learn the Valve
Steps
J
Select Valve Type
JT value

For T3B valves:
value:
0 = 20 mm Direct Fcup
1 = 20 mm
Direct Nonseal
2 = 20 mm Geared Fcup
3 = 20 mm Geared Nonseal
4 = 20 mm Geared O-ring
5 = 1” Direct Fcup
6 = 1” Direct Nonseal
7 = 1” Geared Fcup
8 = 1” Geared Nonseal
9 = 1” Geared O-ring
10 = 2” Direct Fcup
11 = 2” Direct Nonseal
12 = 2” Geared Fcup
13 = 2” Geared Nonseal
14 = 2” Geared O-ring
15 = 60 mm Direct Fcup
16 = 60 mm Direct Nonseal
17 = 60 mm Geared Fcup
18 = 60 mm Geared Nonseal
19 = 60 mm Geared O-ring
20 = 3” Direct Nonseal
21 = 3” Geared Fcup
22 = 3” Geared Nonseal
23 = 4” Direct Nonseal
24 = 4” Geared Fcup
25 = 4” Geared Nonseal
(continued on the next page)
RJT
JT value:
For T3B valves:
0
1
2
3
:
:
42
 = Indicates a factory only setting.
(continued on the next page)
