Mobicool MCF32 User Manual

EN
Intended Use MCF 32, MCF 40 Compressor Cooler
8
6.1 Operating and Display Elements
Lid Latch (fig. 1 )
Operating Panel (fig. 2 )
Connectors (fig. 3 )
Item Description Explanation
1 ON
OFF
Switches the cooler on or off when the button is pressed
for between one and two seconds.
2 POWER Status indication
LED lights up green: The compressor is on.
LED lights up orange: The compressor is off.
LED flashes orange: The display is switched off
automatically due to low
battery voltage.
3 ERROR LED flashes red: The cooler is switched on
but not ready for operation.
4 SET Selects the input mode
– Temperature setting
– Fahrenheit or Celsius display
– Battery monitor setting
5 – Display, shows the information.
6 “+” Press once to increase the value.
7 “–” Press once to decrease the value.
Item Description
1 AC Socket
2 Fuse Holder
3 Cover AC Socket
4 Cover for the DC Socket
5 DC Socket

Mobicool MCF32 Specifications

General

Capacity	31 L
Noise level	49 dB
Certification	CE, E4, GS
Climate class	N-T
Refrigerating medium	R134a
Bottle volume supported	1.5 L
Number of cans supported	52
Cooling temperature range	-10 - 20 °C
Number of bottles supported	6
Refrigerating medium weight	40 g
Power source	Electric
Input current	0.4-4 A
AC input voltage	100-240 V
DC input voltage	12/24 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Product color	Blue, White
Interior light	Yes
Handles quantity	1
Insulation material	Polyurethane (PU)
Package depth	640 mm
Package width	430 mm
Package height	505 mm
Package weight	14500 g

Weight and Dimensions

Depth	365 mm
Width	584 mm
Height	407 mm
Weight	11400 g
