Page #11 background imageLoading...
Page #11 background image
EN
MCF 32, MCF 40 Compressor Cooler Specifications
9
7 Specifications
I
MCF32 MCF40
Operating Voltage 12/24 Vg
120 Vw, 60 Hz
Initial Startup Current 4.5 A (12 Vg)/2.2 A (24 Vg)
1.0 A (120 Vw)
Energy Consumption
(90 °F Ambient, 41 °F Internal)
1.1 A h/h
Cooling Capacity 50 °F to 4 °F
(10 °C to –16 °C)
Gross Capacity 32.5 L 40 L
Usable Capacity 31 L 38 L
Ambient Temperature 61 °F to 90 °F
(16 °C to 32 °C)
Noise Emission 49 dB(A)
Refrigerant Quantity 1.4 oz (40 g) 1.5 oz (42 g)
CO
2
Equivalent 0.057 t 0.060 t
Global Warming Potential
(GWP)*
1430
Dimensions (L x W x H) 23 x 14.4 x 16 in.
(584 x 365 x 407 mm)
23 x 14.4 x 17.5 in.
(584 x 365 x 446 mm)
Weight 25.1 lbs (11.4 kg) 25.4 lbs (11.5 kg)
NOTE
If the ambient temperature is above 90 °F (32 °C), the minimum temper-
ature cannot be attained.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mobicool MCF32 and is the answer not in the manual?

Mobicool MCF32 Specifications

General IconGeneral
Capacity31 L
Noise level49 dB
CertificationCE, E4, GS
Climate classN-T
Refrigerating mediumR134a
Bottle volume supported1.5 L
Number of cans supported52
Cooling temperature range-10 - 20 °C
Number of bottles supported6
Refrigerating medium weight40 g
Power sourceElectric
Input current0.4-4 A
AC input voltage100-240 V
DC input voltage12/24 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Product colorBlue, White
Interior lightYes
Handles quantity1
Insulation materialPolyurethane (PU)
Package depth640 mm
Package width430 mm
Package height505 mm
Package weight14500 g
Weight and Dimensions IconWeight and Dimensions
Depth365 mm
Width584 mm
Height407 mm
Weight11400 g
