Mobicool MCF32 User Manual

EN
MCF 32, MCF 40 Compressor Cooler Operation
11
8.4 Using the Battery Monitor
The cooler is equipped with a multi-level battery monitor that protects your vehicle
battery against excessive discharging when the cooler is connected to the DC
power supply.
If the cooler is operated when the vehicle ignition is switched off, the cooler switches
off automatically as soon as the supply voltage falls below a set level. The cooler will
switch back on once the vehicle battery has been recharged to the restart voltage
level.
A
In “HIGH” mode, the battery monitor responds faster than at the levels “LOW” and
“MED”.
Select the battery monitor mode:
1. Switch on the cooler.
2. Press the “SET” button three times.
3. Use the “+” and “–” buttons to select the battery monitor mode.
The selected mode appears in the display for a few seconds. The display flashes sev-
eral times before it returns to the current temperature.
I
NOTICE!
When switched off by the cooler battery monitor, the vehicle battery will
no longer be fully charged. Avoid starting repeatedly or operating items
that consume vehicle battery current without longer vehicle charging
phases. Failure to obey this notice could result in a discharged or inop-
erable vehicle battery.
Battery Monitor Mode
LOW MED HIGH
Switch-Off Voltage at 12 V 10.1 V 11.4 V 11.8 V
Restart Voltage at 12 V 11.1 V 12.2 V 12.6 V
Switch-Off Voltage at 24 V 21.5 V 24.1 V 24.6 V
Restart Voltage at 24 V 23.0 V 25.3 V 26.2 V
NOTE
When the cooler’s power is supplied by the vehicle battery, select the
battery monitor mode “HIGH”. If the cooler is connected to a battery,
the battery power supply, the monitor mode “LOW” will suffice.

Mobicool MCF32 Specifications

General

Capacity	31 L
Noise level	49 dB
Certification	CE, E4, GS
Climate class	N-T
Refrigerating medium	R134a
Bottle volume supported	1.5 L
Number of cans supported	52
Cooling temperature range	-10 - 20 °C
Number of bottles supported	6
Refrigerating medium weight	40 g
Power source	Electric
Input current	0.4-4 A
AC input voltage	100-240 V
DC input voltage	12/24 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Product color	Blue, White
Interior light	Yes
Handles quantity	1
Insulation material	Polyurethane (PU)
Package depth	640 mm
Package width	430 mm
Package height	505 mm
Package weight	14500 g

Weight and Dimensions

Depth	365 mm
Width	584 mm
Height	407 mm
Weight	11400 g
