Provided hardware:
Components Carton Placement
E
F
x11
x8
A
x42Cam Bolt Ø6 x 35 mm
B
x34Cam Lock Ø15 mm
D
x4Screw M 6.4 x 25 mm
C
x41Wood Dowel Ø8 x 30 mm
Screw M 8 x 39 mm
Shelf Pin
G
x4Screw Cap Ø15 mm
H
x2Stopper
I
x2Handle
What you need:
Phillips Head Screwdriver
Phillips
Plate
W
x1
Rubber
X
x2
J
K
x2
x4
Screw M 4 x 20 mm
Floor Protector
Drawer Runner
RM30A
x2
Hinge
HS26C
x6
S
T
x4
x2
Wood Dowel Ø6 x 30 mm
Screw M 7 x 50 mm
Screw M 6 x 10.5 mm
U
x8
V
x12
Screw M 3.5 x 13 mm
Carton 1 of 2
Screw M 4.5 x 12.5 mm
L
x40
M
x20
Wedge
Screw M 3.5 x 15.5 mm
N
O
x4
x20
Handle
P
x2Allen Key
Q
x1List Join
R
x8Cam Lock Ø12 mm
3
x1Side Board Left
4
x1Side Board Right
8
x1Door Left
9
x1Door Right
14
x1PVC Board
26
x2Back Board
x1Hardware Pack
Label
QtyDescription
Carton 2 of 2
1
x1Top Board
2
x1Bottom Board
5
x2Adjustable Shelf
6
x1Fixed Shelf
7
x1Bottom Skirt
10
x2Support Board 1 Hutch
11
x3Support Board 2 Hutch
12
x1Front Board Hutch
13
x1Back Board Hutch
16
x2Support Board 2
17
x1Side Board Drawer 1
15
x2Support Board 1
Label
QtyDescription
18
x1Side Board Drawer 2
19
x1Side Board Drawer 3
21
x2Front Drawer
22
x2Side Drawer Left
23
x2Side Drawer Right
24
x2Back Drawer
25
x2Bottom Drawer
Label
QtyDescription
