5014166 D 55
4
Transmitted Light Option Operations
The ImageXpress
®
Transmitted Light option is designed for phase-
contrast transmitted-light imaging. In general terms, transmitted light is
used to describe microscopy in which light is transmitted from a source
on one side of the specimen, with the objective on the other side.
Typically the light is first passed through a condenser so high illumination
is focused on the specimen. For more information on phase contrast
microscopy, visit the Nikon website:
www.microscopyu.com/articles/phasecontrast/phasemicroscopy.html
The ImageXpress Transmitted Light option can be installed with or
without the Environment Control option. It is not compatible with the
Fluidics option.
See Also:
• Environment Control Option Operations on page 9
This chapter contains the following sections:
• Transmitted Light Hardware on page 56
• Transmitted Light Software Configuration on page 59
• Transmitted Light Phase Ring Alignment on page 61
ImageXpressOptionsUserGuide.book Page 55 Wednesday, September 9, 2015 3:54 PM
