ImageXpress Micro High Content Imaging System Options User Guide
58 5014166 D
Figure 4-3: Transmitted Light shutter
1
2
4
3
Figure 4-4: Hinge-release knob and hinge
Item Description
1 Hinge-release knob
2 Hinge
3 Hinge-release knob
4 Assembly tipped back with hinge-release knob unscrewed
