9
SETTING OF WORK LOAD
If you intend to exercise with a work load of 50 watts
and a pedalling speed of 24 km/h (60 rpm), do as fol-
lows:
Check on the RPM-display of the meter that you have
achieved the correct pedalling speed.
After that the tension handwheel should be adjusted
so that 50 watts are shown on the scale for 24 km/h.
Power conversion table at other pedalling speeds
The conversion table below shows the conversion into
watts at other pedalling speeds than 24 and 28 km/h
respectively. The result is achieved according to the fol-
lowing example:
Chose as work load any of the watt numbers on the
scale for 24 km/h at the same time as you pedal with
this speed.
Let us imagine that you have chosen 120 watts as work
load. If you now increase the pedalling speed to 90
rpm the table should be read as follows:
Start from the line 24 km/h and continue to 120 watt
and further to the line for 90 rpm. You can then read
that the actual power is 180 watts. See the markings in
the table below.
50 watt
Tension
handwheel
Fig 10
Watts indicated
on the scale for
24 km/h
Actual speed
and actual
work load
RPM km/h WORK LOAD watt
40 16 20 40 60 80 100 120 140 160 180 200
50 20 25 50 75 100 125 150 175 200 225 250
60 24 30 60 90 120 150 180 210 240 270 300
70 28 35 70 105 140 175 210 245 280 315 350
80 32 40 80 120 160 200 240 280 320 265 400
90 36 45 90 135 180 225 270 315 360 405 450
100 40 50 100 150 200 250 300 350 400 450 500
110 44 55 110 165 220 275 330 385 440 495 550
120 48 60 120 180 240 300 360 420 480 540 600
