1 For Reference Only BURNER GAS PIPE
2 For Reference Only FIXING BRACKET FOR IONIZATION
PROBE
3 9005 GAS VALVE
4 For Reference Only FIXING BRACKET FOR BURNER
MZTHR
5 9024 FLUE LIMIT 76º C.
6 9058 CONDENSATE TRAP
7 9059 SIGHT GLASS
8 9060 SIGHT GLASS RETAINER
9 For Reference Only GAS SUPPLY
10 For Reference Only NON-RETURN VALVE
11 9011 SAFETY VALVE MF 1/2"
12 9012 EXPANSION TANK
13 For Reference Only FLEXIBLE PIPE/SIPHON
OUTLET D 32 LENGTH 1300
14 9057 STRAINER
15 For Reference Only DRAIN VALVE WITH
CAP M 1/2 - M 3/4
16 9025 CONNECTING TUBE
(EXPANSION TANK)
17 9068/9078 WASHER
18 9056 STRAINER
19 For Reference Only HEATING FLOW/RETURN UNIT
APPENDIX B
DESCRIPTION
ITEM
#
PART
NUMBER
DESCRIPTION
ITEM
#
PART
NUMBER
20 For Reference Only CIRCULATING PUMP 15/42F 115V
21 For Reference Only FIXING BRACKET/TURBINE
22 For Reference Only VERSILIC 6X10 LG 300 MM
23 For Reference Only JOINT BRIDGE CIRCULATOR UPS
15-42 F D.55 EP.5
24 For Reference Only FIXING U-PART FOR THE TURBINE
25 9084 LP CONVERSION KIT MZ40
26 9019 FAN (OR #W00. 17073)
27 For Reference Only SLEEVE BURN/VALVE 2
PARTS TO CLIP
28 For Reference Only JOINT TORQUE NITRILE
29 For Reference Only SYSTEM SHELL
30 9098 RETURN TO HX PIPE
31 9099 RETURN TO HX PIPE GASKET
32 For Reference Only GLASS BRAID RING D 12 LG 685
33 9023 SYSTEM LIMIT
34 9022 BURNER HEAD
35 9004 IGNITOR
36 For Reference Only ADAPTER D. 4-D 6.35
REF: CABGEM02 (MZ USA)
37 9003 FLAME PROBE
38 For Reference Only HEATING FLOW BEND
