Moons' SSDC-D Series User Manual

41
Rev. 1.0
10/21/2018
SSDC-D/IP Hardware Manual
400-820-9661
AM23SS-N-BR01 Series(With brake)
47.14
47.14
Ø38.1
4-Ø5.1
56.3
A
A1 FLAT
B
B1
1.6
L
7
30033
73.6
41
Model A A1 B B1 L Connector On Cable
AM23SS2DGA-N-BR01
φ
8 7.5 24 20 77.5
Motor cable
Housing: 39-01-3048 (Molex)
，
1pcs
Crimp: 39-00-0038 (Molex)
，
4pcs
Encoder cable
Housing: 1-1827864-0 (Tyco)
，
1pcs
Crimp: 1827569-2 (Tyco)
，
15pcs
AM23SS2DGB-N-BR01
φ
6.35 5.85 20 15 77.5
AM23SS3DGA-N-BR01
φ
8 7.5 24 20 99.5
AM23SS3DGB-N-BR01
φ
6.35 5.85 20 15 99.5
AM23SS4DGA-N-BR01
φ
8 7.5 24 20 102.5
Specification of brake for NEMA23motor
Model
Voltage Torque
Power
Reactive time Life Maximum speed
Insulation class
(VDC) (N.m) (ms) (times) (rpm)
NEMA23 Brake
24 1.2 4.5 50 10000 5000 Class B
