42
Rev. 1.0
10/21/2018
SSDC-D/IP Hardware Manual
400-820-9661
AM24SS-N-BR01 Series(With brake)
B1
B
A1 FLAT
A
47.14
47.14
Ø38.1
60
4-Ø4.5
1.5
8
111
77.4
33
300
41
Model A A1 B B1 Connector On Cable
AM24SS3DGA-N-BR01
φ
10 9.5 24 20
Motor cable
Housing: 39-01-3048 (Molex)
1pcs
Crimp: 39-00-0038 (Molex)
4pcs
Encoder cable
Housing: 1-1827864-0 (Tyco)
1pcs
Crimp: 1827569-2 (Tyco)
15pcs
AM24SS3DGB-N-BR01
φ
8 7.5 20.6 15
Specification of brake for NEMA24 motor
Model
Voltage Torque
Power
Reactive time Life Maximum speed
Insulation class
(VDC) (N.m) (ms) (times) (rpm)
NEMA24 Brake
24 1.2 4.5 50 10000 5000 Class B
