35
Rev. 1.0
10/22/2018
SSDC-R/C Hardware Manual
400-820-9661
6 Reference Materials
6.1 Drive Mechanical Outlines
Unit:mm
Model
SSDC03-R SSDC06-R SSDC10-R
SSDC03-C SSDC06-C SSDC10-C
