Moons' SSDC-R Series User Manual

48
Rev. 1.0
10/22/2018
SSDC-R/C Hardware Manual
400-820-9661
7 Accessories
7.1 Standard Accessories（Included）
• -R Type
Model Number Catagory Vendor Description
1103-200 1 Cable / Power supply cable
2012-030 1 Cable / 0.3m network cable
Screwdriver 1 Screwdriver / Screwdriver
39-01-3048 1 Housing Molex Motor connector housing
（
J2
）
501646-1600 1 Housing Molex Encoder connector housing
（
J3
）
501646-3200 1 Housing Molex I/O connector housing
（
J4
）
39-00-0038 5 Crimp Molex Motor connector crimp
501648-1000 52 Crimp Molex Encoder & I/O connector crimp
• -C Type
Model Number Catagory Vendor Description
1103-200 1 Cable / Power supply cable
2019-150 1 Cable / RS-232 configuration cable
2012-030 1 Cable / 0.3m network cable
Screwdriver 1 Screwdriver / Screwdriver
39-01-3048 1 Housing Molex Motor connector housing
（
J2
）
501646-1600 1 Housing Molex Encoder connector housing
（
J3
）
501646-3200 1 Housing Molex I/O connector housing
（
J4
）
39-00-0038 5 Crimp Molex Motor connector crimp
501648-1000 52 Crimp Molex Encoder & I/O connector crimp
7.2 Optional Accessories (Sold separately)
Model Catagory Description
RC880 Regeneration Clamp Regeneration Clamp
MS-USB-RS232-01 USB Converter USB to RS-232
MS-USB-RS485-01 USB Converter USB to RS-485
MS-USB-CAN-01 USB Converter USB to RS-CAN
1117-口口口 Cable I/O Cable
2109-口口口-口口口 Cable Extended motor cable
（
For SSDC drive and AM11RS motor
）
2103-口口口-口口口 Cable Extended motor cable
（
For SSDC drive and AM17/23/24/34SS-N
、
AM17/23/24/34RS motor
）
2118-口口口-口口口 Cable Extended encoder cable
（
For SSDC drive and AM11RS motor
）
2117-口口口-口口口 Cable Extended encoder cable
（
For SSDC drive and AM17/23/24/34SS-N motor
）
2116-口口口-口口口 Cable Extended encoder cable
（
For SSDC drive and AM17/23/24/34RS motor
）
201口-口口口 Cable Network Cable
