SSDC-R/C Hardware Manual
400-820-9661
AM23 Series
47.14
4 7.14
V38.1
4-V5.1
56.3
A
A 1
B
B1
1.6L
7
30033
7 3.6
Model A A1 B B1 L Connector On Cable
AM23RS2DMA
φ
8 7.5 24 20 77.5
Motor cable
Housing: 39-01-3048 (Molex)
，
1pcs
Crimp: 39-00-0038 (Molex)
，
4pcs
Encoder cable
Housing: 1-1827864-6 (Tyco)
，
1pcs
Crimp: 1827569-2 (Tyco)
，
11pcs
AM23RS2DMB
φ
6.35 5.85 20 15 77.5
AM23RS3DMA
φ
8 7.5 24 20 99.5
AM23RS3DMB
φ
6.35 5.85 20 15 99.5
AM23RS4DMA
φ
8 7.5 24 20 102.5
AM23SS2DGA-N
φ
8 7.5 24 20 77.5
Motor cable
Housing: 39-01-3048 (Molex)
，
1pcs
Crimp: 39-00-0038 (Molex)
，
4pcs
Encoder cable
Housing: 1-1827864-0 (Tyco)
，
1pcs
Crimp: 1827569-2 (Tyco)
，
15pcs
AM23SS2DGB-N
φ
6.35 5.85 20 15 77.5
AM23SS3DGA-N
φ
8 7.5 24 20 99.5
AM23SS3DGB-N
φ
6.35 5.85 20 15 99.5
AM23SS4DGA-N
φ
8 7.5 24 20 102.5
