535 User's Manual Chapter 5 31
Controller Set Up
Access Set Up Return to Operation Next menu Next parameter Next value Access Tuning Return to Operation
+
FAST MENU
DISPLAY
+
MENU MENU
▲ ▼
MENU DISPLAYFAST
6. OUTPUT 3
Defines the function of the third output.
• ALM.RLY:ON
• ALM.RLY:OFF
• RETRANS. Retransmission
• COMM. ONLY Output addressable through communications
D OFF Completely deactivates the output
7. OUTPUT 4
Defines the function of the fourth output.
• ALM.RLY:ON
• ALM.RLY:OFF
• RETRANS. Retransmission
• COMM. ONLY Output addressable through communications
D OFF Completely deactivates the output
8. ANLG. RNG.:1
Defines the output signal for the first output.
D 4–20 mA
• 0–20 mA
• 20–4 mA
• 20–0 mA
9. ANLG. RNG.:2
Defines the output signal for the second output.
D 4–20 mA
• 0–20 mA
• 20–4 mA
• 20–0 mA
10. ANLG. RNG.:3
Defines the output signal for the third output.
D 4–20 mA
• 0–20 mA
• 20–4 mA
• 20–0 mA
11. ANLG. RNG.:4
Defines the output signal for the fourth output.
D 4–20 mA
• 0–20 mA
• 20–4 mA
• 20–0 mA
OUTPUT 3
OFF
ANLG.RNG.:1
4-20 mA
ANLG.RNG.:2
4-20mA
ANLG.RNG.:3
4-20mA
ANLG.RNG.:4
4-20mA
OUTPUT 4
OFF
