Controller Set Up
Access Set Up Return to Operation Next menu Next parameter Next value Access Tuning Return to Operation
+
FAST MENU
DISPLAY
+
MENU MENU
▲ ▼
MENU DISPLAYFAST
46 Chapter 5 535 User's Manual
REM. SETPT.
This menu appears only if parameter REM. SETPT (of the CONFIG. menu) =
ENABLED.
1. TYPE V/mA
Specifies the type of input signal that will be used for remote setpoint.
D 1-5 /4-20 1–5 volt or 4–20 mA remote setpoint
• 0-5/0-20 0–5 volt or 0–20 mA remote setpoint
2. RSP:LO RNG.
Specifies the engineering unit value corresponding to the lowest remote
setpoint input value, e.g. 4 mA.
R -9999 to 99999
D 0
3. RSP:HI RNG.
Specifies the engineering unit value corresponding to the highest remote
setpoint input value, e.g. 20 mA.
R –9999 to 99999
D 1000
4. RSP: LOW
Defines the lowest setpoint value to be accepted from the remote setpoint
source.
R –9999 to 99999.
D Dependent on RSP:LO.RNG. value.
5. RSP: HIGH
Defines the highest setpoint value from a remote setpoint source.
R –9999 to 99999
D Dependent on RSP:HI.RNG. value
6. TRACKING
Defines whether the local setpoints 1 to 8 will track the remote setpoint.
D NO
• YES
7. BIAS LOW
Defines the lowest bias value that may be entered.
R –9999 to 99999. Maximum value is BIAS HIGH.
D –1000
8. BIAS HIGH
Defines the highest bias value that may be entered.
R –9999 to 99999. Minimum value is BIAS LOW.
D 1000
RSP:LOW
(D)
RSP:HIGH
(D)
TRACKING
NO
BIAS LOW
-1000
BIAS HIGH
1000
REM. SETPT.
RSP. TYPE
1-5 4-20
RSP:LO RNG.
0
RSP:HI RNG.
1000
