Controller Set Up
Access Set Up Return to Operation Next menu Next parameter Next value Access Tuning Return to Operation
+
FAST MENU
DISPLAY
+
MENU MENU
▲ ▼
MENU DISPLAYFAST
14. CONTACT 3
Defines the operation of the third digital input.
• REM. SETPT. Makes the remote setpoint active
• MANUAL Trips the controller to manual control
D 2ND. SETPT. Makes the second setpoint active
• 2ND. PID Makes the second set of PID values active
• ALARM ACK. Acknowledges alarms
• RST. INHBT. Deactivates the reset term
• D.A./R.A. Switches the control action
• STOP A/T Suspends the adaptive tune function
• LOCK. MAN. Locks controller in manual control
• UP KEY Remote
▲▲
▲▲
▲ function
• DOWN KEY Remote
▼ ▼
▼ ▼
▼ function
• DISP KEY Toggle between SP DEV or OUT%
• FAST KEY Activates FAST key
• MENU KEY Activates MENU key.
• COMM. ONLY Status readable only through communications
• PV2.SWITCH Switches between PV1 and PV2
15. CONTACT 4
Defines the operation of the fourth digital input.
• REM. SETPT. Makes the remote setpoint active
• MANUAL Trips the controller to manual control
• 2ND. SETPT. Makes the second setpoint active
D 2ND. PID Makes the second set of PID values active
• ALARM ACK. Acknowledges alarms
• RST. INHBT. Deactivates the reset term
• D.A./R.A. Switches the control action
• STOP A/T Suspends the adaptive tune function
• LOCK. MAN. Locks controller in manual control
• UP KEY Remote
▲▲
▲▲
▲ function
• DOWN KEY Remote
▼▼
▼▼
▼ function
• DISP KEY Toggle between SP DEV or OUT%
• FAST KEY Activates FAST key
• MENU KEY Activates MENU key.
• COMM. ONLY Status readable only through communications
• PV2.SWITCH Switches between PV1 and PV2
CONTACT 4
2ND. PID
CONTACT 3
2ND. SETPT.
