Controller Set Up
Access Set Up Return to Operation Next menu Next parameter Next value Access Tuning Return to Operation
+
FAST MENU
DISPLAY
+
MENU MENU
▲ ▼
MENU DISPLAYFAST
40 Chapter 5 535 User's Manual
6. HIGH OUT.
Defines the highest output value that can be achieved in automatic control.
R 0 – 100% Min is LOW OUT
D 100%
7. ACTION:2
Defines the action of the second control output.
D DIRECT
• REVERSE
8. P.P. TYPE
Defines the type of position proportioning algorithm. Choose values based on
the process.
Feedback option installed Feedback option not installed
D SLIDEWIRE • SLIDEWIRE
• VELOCITY D VELOCITY
9. CCW TIME
Defines the time it takes a motor to fully stroke counter clockwise.
R 1 to 200 seconds
D 60 seconds
10. CW TIME
Defines the time it takes a motor to fully stroke clockwise .
R 1 to 200 seconds
D 60 seconds
11. MIN. TIME
Defines the minimum amount of time the controller must specify for the motor to
be on before it takes action.
R 0.1 to 10.0 seconds
D 0.1 seconds
12. S/W RANGE
Specifies the full range resistance of the slide (e.g., 100 ohms)
R 0–1050 Ohms
D 100 Ohms
13. OPEN F/B
Defines the feedback ohm value corresponding to full open (100% output).
R 0 to S/W RANGE
D Dependent on S/W RANGE value
P.P. TYPE
(D)
CCW TIME
60
CW TIME
60
MIN. TIME
0.1
S/W RANGE
100
HIGH OUT.
100
ACTION:2
DIRECT
OPEN F/B
(D)
