Controller Set Up
Access Set Up Return to Operation Next menu Next parameter Next value Access Tuning Return to Operation
+
FAST MENU
DISPLAY
+
MENU MENU
▲ ▼
MENU DISPLAYFAST
42 Chapter 5 535 User's Manual
3. ALARM SP:1
Specifies the alarm set point for alarm 1 (except HIGH/LOW)
For HIGH or LOW alarms:
If ALM.SRC.:1 = OUTPUT If ALM.SRC.:1 = any other type
R 0.0% to 100.0% R LOW RANGE to HI RANGE
D 0.0% D 0
For BAND alarms:
R 1 to 99999
D 0
For DEVIATION or RATE alarms:
R -9999 to 99999
D 0
4A.HIGH SP:1
Specifies the high alarm set point for alarm 1 of type HIGH/LOW.
If ALM.SRC.:1 = OUTPUT If ALM.SRC.:1 = any other type
R 0.0% to 100.0% R LOW RANGE to HI RANGE
D 0.0% D 0
4B.LOW SP:1
Specifies the low alarm set point for alarm 1 of type HIGH/LOW.
If ALM.SRC.:1 = OUTPUT If ALM.SRC.:1 = any other type
R 0.0% to 100.0% R LOW RANGE to HI RANGE
D 0.0% D 0
5. DEADBAND:1
Defines the deadband for alarm 1.
If ALM.SRC.:1 = OUTPUT If ALM.SRC.:1 = any other type
R 0.1% to 100.0% R 1 to 99999
D 2 D 2
6. ALM.:1 OUT.
Selects the output number for alarm 1.
D NONE
•2
•3
•4
7. LATCHING:1
Defines the latching sequence of alarm 1.
D LATCH
• NO LATCH
ALARM SP:1
0.0%
ALM.:1 OUT
NONE
DEADBAND:1
2
HIGH SP:1
0.0%
LOW SP:1
0.0%
LATCHING:1
NONE
